Light Weight Thermal Scope Sight High Performance 2x / PIP / 4x Zoom Available
lightest and most compact thermal weapon sight in its class with great image performance
Thermal Imaging Sight NightSeer 335R
The NightSeer 335R is one of the most advanced and small thermal imaging rifle sight systems for Security, surveillance, hunting, and military applications. The NightSeer 335R thermal imaging sight offers superiors clarity, versatility, reliability, functionality, and value. Based on the proven 17Um microbolometer core, the NightSeer thermal hunting sight is an ideal product for force protection, border patrol officers, police SWAT officers, and special operations forces, providing users with the necessary tools to be successful in both day-time and night-time.
Find the features
◆ Intelligent Coloration allows the user to better bring out the target or the background depending on conditions.
◆ Ergonomic design with five-position thumbstick for one-hand operation
◆ User-friendly interface, The NightSeer-R is designed with ease-of-operation in mind. User feedback has resulted in the most friendly interface to date
◆ WIFI and photo/video onboard recording
| Technical Data Sheet of Thermal Imager NightSeer335 Series |
| | NS335-R |
| Microbolometer | |
| Type | Uncooled |
| Resolution, pixels | 384×288 |
| Frame Rate, Hz | 50 |
| Pixel size, um | 17 |
| NETD | less than 50mk |
| Optical Characteristics | |
| Objective Lens | 35mm, F/1.1 |
| Magnification, X | 1.9 |
| Zoom | 2x/PIP/4X |
| Eye Relief, mm | 60mm |
| Dioptre Adjustment, D | ±5 |
| FOV | 10.6°×8.0° |
| Close-up range,m | 5 |
| Display | |
| Type | OLED |
| Resolution, pixel | 1024×768 |
| Detection Range (1.7m target) | 1350 |
| Recognition Range (1.7m) | 450 |
| Detection Range (2.3m target) | 1800 |
| Recognition Range (2.3m) | 600 |
| Reticle | |
| Accuracy(per pixel) | 0.62MOA |
| Click range(x,y) | 238 MOA |
| Power Supply | |
| Battery Type | 2XCR123 |
| Power Supply | 3.6～7.2 |
| External Power Supply | 5v USB |
| Operation Time on a battery set(standard version),h | 5 |
| Operation Time on external battery pack(standard version),h(13000mAh) | 44 |
| Video recorder (optional) | |
| Video/Photo format | avi/jpg |
| Built-in memory(optional) | 32G |
| Wifi Channel(optional) | |
| Frequency | 2.4 |
| Reception range,m | 15 |
| Physical Parameters | |
| Degree of Protection | IP67 |
| Operation Temperature | —25°C～+50°C |
| Storage Temperature | —40°C～+70°C |
| Shock and Vibration | 1000g/ms |
| MTBF | More than 800h |
| Weight without batteries,g | 380 |
| Dimension, mm | 176×65×67 |
QUALITY CONTROL
We understand that, in some cases, lives may depend on the performance of our products, that is why every unit that leaves our facility must pass tough quality control standards testing.
It is our mission to continue to design, build, test and ship the very best optoelectronic devices on the market.
